廠家直銷otp燒錄8腳SOP語音芯片
價格：0.90元
型號：SKV020G
包裝：SOP8
品牌：sikewei
思科微電子專注于語音芯片及語音模塊的開發設計與制作,同時從事各種語音IC芯片,語音識別芯片,音樂芯片,MP3解碼芯片,語音芯片產品型號齊全,免費提供電路圖設計方案TEL:0755-29124379
MAX voice file : 700
MAX Trigger Groups : 63
Power On Trigger Group :1
MAX Step : 700
Signal step mute length : 0.64 s ( 6k sample rate )
Operating Voltage range: 2.4V ~ 5.0V
Total Voice Duration : Depend on Flash ROM size.
I/O pin : 8
Voice output : PWM or DAC
Sequential Key : TG1 -> 32 Groups / 63 Groups(Single TG).
TG2 -> 29 Groups.
TG3~TG8-> 1 Group
De-bounce time : 50 us or 10 ms
On/Off function : only for all TH PIN
Sequential Key for Volume control function.
Step can change Trigger I/O Type, Trigger Mode & Output Status.
Hardware Trigger Group Repeat function.
Simple Programming Function :
(a) Write data to working register.
(b) Working Register Increasing.
(c) Step Jump by Working Register / Volume Status.
